SPROLINK VF4
4.150,00€ c/IVA
- Estimate delivery times: 3-5 days (Portugal Continental), 5-7 days (Portugal Ilhas)
- Returns accepted if product not as described, seller pays return shipping; or keep the product & agree refund with seller
- Easy payment online or bank wire transfer (Portugal)
Details & Description
SPROLINK VF4
4K LED Video Processor with HDR
- true 4K video processor with 4K 60Hz 4:4:4 in and out for LED displays.
- HDR10 processing for enhanced image quality
- Ideal for working with 4K LED sender card
Seamless Scaling and Switching within 4K resolution
Multiple Devices Cascade Splicing for LED displays beyond 4K
4K 60Hz any channel multi-layer layout
Support HDR Color Reduction and Enhancement
Support DP1.2 / HDMI2.0 4K@60Hz Input
Support HDMI2.0 4K@60Hz Output
Support Any 4k Preview Input
Support Any 4K PIP Input Channel
Support EDID Management, P2P Display
Support Cascade Split Support Embedded Audio Decoder, Video and Audio Synchronization
Support 420 | 422 | 444 Video Format
Support Open Control Protocol
Support PIP
HDR10 Color Reduction and Enhancement
HDR (High Dynamic Range) provides more dynamic range and image detail than normal images, depending on the LDR (Low-Dynamic Range) image for different exposure times.
The HDR image is synthesized with the LDR image, corresponding to the best detail for each exposure time, which can better reflect the visual effect in the real environment. Under the action of HDR10, VF4 video processor showing more vivid. It can be alternated between cool and warm colors. 4K HDR is an advanced image processing technology than 4K. With HDR movies and VF4 video processor’s processing, the video will be more brilliant.
4K Preview
VF4 with preview for monitoring, making the live show more safety.
4K PIP
VF4 support any 4K channel PIP or PBP display.
Multi-Cascade
Support 4K60hz output, multi-cascade support 8K, 12K, 16K display. The backup output ensure the live show safety and also save your cost.
Multi-layer Display
Support multi-layer 4k signal display, different layout switch.
|
Input Interface |
Standard |
2 × HDMI 1.4(4K@30Hz) |
|
Optional |
1 × 3G/HD/SD SDI |
|
|
Output Interface |
Standard |
1 × HDMI 2.0(Main Ouput) |
|
Operation |
RS232 USB |
Open protocol control USB upgrade |
|
Input Resolution |
HDMI |
SMPTE: 720p | 1080p | 2160p |
|
DP |
SMPTE: 720p | 1080p | 2160p |
|
|
VGA |
800×600 | 1024×768 | 1280×1024 | 1600×1200 | 1920×1080 | 1920×1200 |
|
|
SDI |
480i | 576i |720p | 1080i | 1080p | 1080psf |
|
|
Frame |
23.98/24/25/29.97/30/50/59.94/60Hz |
|
|
Output Resolution |
SMPTE VESA |
720p | 1080p 1024×768 | 1280×720 | 1600×1200 | 1920×1080 |1920×1200 | 2048×1152 | 3840×1080 | 3840×2160 | 4096×2160 Customized point to point display |
|
Supoort Protocol |
HDMI |
1.3 | 1.4 | 2.0 |
|
DP |
1.1 | 1.1a | 1.2 |
|
|
SDI |
SD-SDI、HD-SDI、3G-SDI |
|
|
VGA |
VGA-UXGA |
|
|
Input voltage |
AC 100~264V(Typical value10/220) 50/60Hz |
|
|
Max power |
20W |
|
|
TEMP |
-25°C~55°C(Typical value25°C) |
|
|
Humidity |
20%~90% |
|
|
Weight |
3.0kg(Equipment Weight)) 6.0kg(Transport Weight)) |
|
|
Size |
480mm x 320mm x 67mm (Equipment Size) 540mm x 380mm x 140mm (Transport Size) |
|
- VF4 PRO Video processor
- User manual
- 1 year warranty
Specifications
Additional information
| Weight | 3 kg |
|---|---|
| Dimensions | 48 × 32 × 6,7 cm |
Reviews
There are no reviews yet.
