BirdDog Eyes P200 1080p Full NDI PTZ Camera

2.595,00 c/IVA

Available on backorder

  • Estimate delivery times: 3-5 days (Portugal Continental), 5-7 days (Portugal Ilhas)
  • Returns accepted if product not as described, seller pays return shipping; or keep the product & agree refund with seller
  • Easy payment online or bank wire transfer (Portugal)
Compare
SKU: BDP200 Categories: , ,

2.595,00 c/IVA

Clear

Details & Description

BirdDog Eyes P200 1080p Full NDI PTZ Camera

Combining BirdDog’s custom NDI silicon chip, 30x optical zoom, and Sony backlit sensor and image module, the BirdDog Eyes P200, in black, is a full NDI 1080p60 PTZ camera designed for large indoor spaces. Thanks to the fast autofocus and zoom ensured by the true Sony image module, the P200 is highly suitable for catching all the fast action in places such as sporting events. As opposed to other types of NDI, such as NDI|HX, which is a compressed variant that reaches 12 Mb/s, the P200 features the visually lossless full NDI variable bit-rate iFrame codec that reaches up to 140 Mb/s at 1080p60.

Simultaneous, live SDI, HDMI, and full NDI outputs complete the camera as a comprehensive solution. Between these connections, you can control the P200 live via your full NDI workflow or integrate RS-422, RS-485, and RS-232 serial control. Also, the optional BirdDog PTZ Keyboard can be used over NDI or over RS-422/RS-232 in SDI mode. The P200 can be powered by Power-over-Ethernet (PoE) or via the included power adapter.

The Eyes P200 also comes with the BirdDog Comms Lite audio intercom software, which supports up to four BirdDog devices. Comms Lite is Windows-compatible and offers features such as director push to talk, mute camera operator, auto-detect NDI sources, monitor camera audio, and shortcut to Web console. For a more complete version of the application, an optional upgrade is available to Comms Pro. The camera is also compatible with the optional BirdDog Central software, which helps you decode NDI back to HDMI or SDI.

  • Fast 30x optical zoom and autofocus thanks to the use of a true Sony image module
  • Highly suitable for capturing the fast action in sporting events
  • Designed for large indoor spaces such as sports stadiums, school auditoriums, and large meeting rooms
  • BirdDog custom NDI silicon chip; up to 140 Mb/s 1080p60 full NDI
  • Sony backlit sensor
  • Simultaneous, live SDI, HDMI, full NDI, and CVBS outputs
  • NDI and RS-422/RS-485/RS-232 control via dedicated RJ45 ports
  • Optional BirdDog PTZ Keyboard supported
  • Image stabilizer function when zoom is set to 30x ensures less screen blur
  • True WDR 130 dB
  • 128 presets at speeds up to 150°/sec (up to six presets can be stored in the included remote control
  • Audio input and output support with NDI streaming
  • Powered via Power-over-Ethernet (PoE) or the included power adapter
  • Includes BirdDog Comms Lite audio intercom software (Windows)

CAMERA

IMAGE SENSOR
1 / 2.8 inch CMOS 2.13MP

LENS
4.3-129mm

OPTICAL ZOOM
30x

DIGITAL ZOOM
12x

HORIZONTAL ANGLE OF VIEW
63.7° (W) – 2.3°(T)

APERTURE
F1.6 (W) – F4.7 (T)

MIN. ILLUMINATION
Color: 0.01 lux (F1.6, AGC on, 1/30s, High sensitive mode), 0.1 lux (F1.6, AGC on, 1/30s, Normal sensitive mode)

SHUTTER SPEED
1/1 – 1/10000s

FOCUS
Auto, Push, Manual

WHITE BALANCE
Auto, Indoor, Outdoor, Manual, OPW, ATW

EXPOSURE
Auto, Manual, Shutter/Iris Priority

BACKLIGHT COMPENSATION
YES

MECHANICAL

PAN MOVEMENT
Horizontal: ±350º continuous pan (Zoom Adaptive Speed Range: 0.05º〜100º/S )

TILT MOVEMENT
Vertical: +90º to -30º (Zoom Adaptive Speed Range: 0.05°〜50°/S)

PRESET POSITIONS
128 (Speed adjustable: Up to 150°/s)

PRESET SPEED
0-5 Level adjustable

ENVIRONMENTAL
Indoor

OPERATING TEMPERATURE
-10 – +50 (°C)

OPERATING HUMIDITY
≤80%

VIDEO INTERFACE

VIDEO OUTPUT
NDI /HDMI /SDI

VIDEO FORMATS
1080p 60, 59.94, 50, 29.97, 25
1080i 60, 59.94, 50
720p 60, 59.94, 50, 29.97, 25

AUDIO I/O
3.5mm Audio In (Stereo)
3.5mm Audio Out (Stereo)

CONTROL INTERFACE

IP PTZ CONTROL
NDI Control (auto configuring)

SERIAL PTZ CONTROL
2x RJ45: RS232/RS422/RS485

SERIAL CONTROL PROTOCOL
VISCA / Pelco D

POWER & DIMENSIONS

POWER INPUT
12v DCm, PoE+ (IEEE 802.3at)

MAX POWER DRAW
18.19W

DIMENSIONS
160x178x220mm

WEIGHT
2.0Kg

NETWORK

VIDEO COMPRESSION
Full NDI – i-frame high quality low latency NDI for production

NETWORK PROTOCOL
NDI – Discovery, configuration and control

WEB CONTROL INTERFACE
Full control via Web/Mobile UI including Scene presets

  • BirdDog Eyes P200 1080p Full NDI PTZ Camera (Black)
  • Power Adapter
  • Power Cord
  • IR Remote Controller (Required CR2032 Coin Battery Not Included)
  • Bag of Mounting Screws
  • RJ45 to RS-232 Extension Cable
  • RJ45 to RS-422 Extension Cable
  • Limited 1-Year Warranty

BirdDog PTZ Range

Banner P200

Specifications

Additional information

Weight 3 kg
Dimensions 16 × 17,8 × 22 cm
Color

Black, White
