Blackmagic Mini Converter Quad SDI to HDMI 4K
Blackmagic Mini Converter Quad SDI to HDMI 4K (BMD-CONVMBSQUH4K2) . Connect Single Link 6G-SDI, Dual Link 3G-SDI or Quad Link HD-SDI to the newest HDMI 4K projectors and televisions that support Ultra HD over a single HDMI link. Includes SD/HD and Ultra HD auto switching.
The new Blackmagic Mini Converter range are the worlds most advanced converters because they include the latest 6G-SDI technology, plus automatically detect the input video format and instantly change between virtually all SD, HD and Ultra HD video standards! Simply plug in and Mini Converters will convert between your equipment all automatically!
Connect Single Link 6G-SDI, Dual Link 3G-SDI or Quad Link HD-SDI to the newest HDMI 4K projectors and televisions that support Ultra HD over a single HDMI link. Includes SD/HD and Ultra HD auto switching.
The new Blackmagic Mini Converter range are the worlds most advanced converters because they include the latest 6G-SDI technology, plus automatically detect the input video format and instantly change between virtually all SD, HD and Ultra HD video standards! Simply plug in and Mini Converters will convert between your equipment all automatically!
Connect single link, dual link and quad link SDI Ultra HD to the latest Ultra HD projectors and televisions that support Ultra HD over a single HDMI link.
You can also convert any of the following inputs to HDMI:
- SD-SDI to SDTV
- HD-SDI to HDTV
- Single link 3G-SDI
- Single link 6G-SDI
- Dual link HD-SDI
- Dual link 3G-SDI Ultra HD to Ultra HD
- Quad link HD-SDI Ultra HD to Ultra HD
If the HDMI output detects an HD monitor or HDTV, the output signal is automatically down-converted.
| Connections | |
| SDI Video Input | 4 x 1.5G-SDI |
| 2 x 3G-SDI | |
| 1 x 6G-SDI | |
| SDI Video Output | (4K HDMI output only) |
| HDMI | HDMI type A out. |
| Multi Rate Support | Auto detection of 6G-SDI or standard definition on Input 1. |
| Updates | Via USB 2.0 high speed. (480 Mb/s) |
| Reclocking | Yes |
| Standards | |
| SD Format Support | 525/29.97 NTSC, 625/25 PAL |
| HD Format Support | 720p50 |
| 720p59.94 | |
| 720p60 | |
| 1080i50 | |
| 1080i59.94 | |
| 1080i60 | |
| 1080p23.98 | |
| 1080PsF23.98 | |
| 1080p24 | |
| 1080PsF24 | |
| 1080p25 | |
| 1080PsF25 | |
| 1080p29.97 | |
| 1080PsF29.97 | |
| 1080p30 | |
| 1080PsF30 | |
| 1080p50 | |
| 1080p59.94 | |
| 1080p60 | |
| 2K Format Support | 2048x1080PsF23.98 |
| 2048x1080p23.98 | |
| 2048x1080PsF24 | |
| 2048x1080p24 | |
| 2048x1080PsF25 | |
| 2048x1080p25 | |
| 4K Format Support | 3840x2160p23.98 |
| 3840x2160p24 | |
| 3840x2160p25 | |
| 3840x2160p29.97 | |
| 3840x2160p30 | |
| 4096x2160p24 | |
| SDI Compliance | SMPTE 292M, SMPTE 259M, SMPTE 296M, SMPTE 372M, SMPTE 424M and SMPTE 425M. |
| SDI Video Rates | SDI video connections are switchable between standard definition, high definition and 6Gb/s signals. |
| SDI Video Sampling | 4:2:2 and 4:4:4 |
| SDI Audio Sampling | Television standard sample rate of 48 kHz and 24 bit. |
| SDI Color Precision | 4:2:2 and 4:4:4 |
| SDI Color Space | YUV and RGB |
| SDI Auto Switching | Automatically selects between SD SDI, HD-SDI and 6G-SDI. |
| HDMI Format Support | 625/25 PAL |
| 525/29.97 NTSC | |
| 525/23.98 NTSC | |
| 720p50 | |
| 720p60 | |
| 720p59.94 | |
| 1080i50 | |
| 1080i59.94 | |
| 1080i60 | |
| 1080p23.98 | |
| 1080p24 | |
| 1080p25 | |
| 1080p29.97 | |
| 1080p30 | |
| 1080p50 | |
| 1080p59.94 | |
| 1080p60 | |
| 2048x1080p23.98 | |
| 2048x1080p24 | |
| 2048x1080p25 | |
| 3840x2160p23.98 | |
| 3840x2160p24 | |
| 3840x2160p25 | |
| 3840x2160p29.97 | |
| 3840x2160p30 | |
| 4096x2160p24 | |
| Software | |
| Software Control | Mac OS X™ and Windows™ software upgrade via USB. |
| Internal Software Upgrade | Via included updater application. |
| HDMI Color Space | YUV and RGB |
| HDMI Color Precision | 4:2:2 and 4:4:4 |
| Power Requirements | |
| Power Supply | +12V universal power supply included with international socket adapters for all countries. Cable tie point. |
| Power Consumption | 5.2 Watts |
| Operational Voltage Range | 12 – 30 V DC |
| Physical Specifications | Length 110mm x Width 92.27mm x Height 23mm |
| Weight | 257g |
| Environmental Specifications | |
| Operating temperature | 0° to 40° C (32° to 104° F) |
| Storage temperature | -20° to 45° C (-4° to 113° F) |
| Relative Humidity | 0% to 90% non-condensing |
- Mini Converter Quad SDI to HDMI 4K
- 12V universal power supply with international socket adapters
